Real-time text, specified in the open.

Version 1, 2026-08-30. Published at https://www.reos.ai/accessibility/rtt-protocol.

This document is the specification by which real-time text is exchanged between Reos clients. It exists to be read, not only to be implemented: EN 301 549 clause 6.2.3 option (c) requires RTT in a non-PSTN, non-SIP system to use "a relevant and applicable common specification for RTT exchange that is published and available for the environments in which they will be operating", and requires that specification to "include a method for indicating loss or corruption of characters". A format nobody outside the codebase can read satisfies neither half. This does.

It also pre-satisfies EN 301 549 V4.1.0 clause 6.2.10 option (a), which asks only that "the ICT's documentation shall contain information on the main specifications by which RTT is implemented".

1. What this is, in one line

Reos carries an ITU-T T.140 text stream between call participants, framed per IETF RFC 8865 (T.140 Real-Time Text Conversation over WebRTC Data Channels), over the room's existing signalling WebSocket.

2. Scope

• In scope: human-led calls, between participants holding a room token with the role host or guest.
• Out of scope: AI-moderated interviews, which have their own text path. See section 9.
• Not affected: the message-based chat panel, which is a separate feature and a separate clause. RTT is additive.

3. Relationship to RFC 8865, stated exactly

RFC 8865 specifies a T.140 stream on a WebRTC data channel negotiated in SDP with dcmap/dcsa attributes (RFC 8864). Reos conforms to the parts of it that describe the stream and departs from the part that describes the channel. Both halves are stated here rather than glossed, because an overstated conformance claim is worse than a documented deviation.

Conformed

Not conformed, and why

• No SDP negotiation. There is no m=application section, no a=dcmap/a=dcsa, and no SCTP data channel. Reos media runs through a selective forwarding unit whose API exposes no data-channel primitive that maps onto RFC 8864 negotiation, and the room already has a reliable, ordered, authenticated per-participant transport with an identity model. Framing T.140 onto it costs nothing and gains the specification's guarantees; building an SDP-negotiated data channel would gain only the SDP.
• No gateway behaviour (RFC 8865 section 6). Reos interoperates with no RFC 4103 endpoint, because it offers no PSTN dial-in and no SIP bridge. If either is ever added, EN 301 549 clause 6.2.3 options (a) and (b) become applicable and this document stops being sufficient on its own.

4. Character set (the Reos T.140 profile)

Text is Unicode. The following T.140 codes are transmitted and acted on:

The following T.140 codes are not implemented: U+0007 BEL, the INT interrupt sequence, and the ISO 6429 graphic-rendition strings (SGR, SOS, ST, ESC). What is stripped is the character that introduces them - U+001B ESC, U+0098 SOS, U+009C ST - rather than the sequence as a unit, so nothing acts on one; the printable payload of a 7-bit sequence survives as ordinary text, and ESC [ 1 m arrives as [1m. U+FEFF (the T.140 idle/keep-alive character) is accepted and discarded; Reos does not need a keep-alive because the room WebSocket has its own.

All other C0 and C1 control characters are stripped.

Erasure unit. BACKSPACE erases one user-perceived character, not one UTF-16 code unit: an astral code point, a base character with its combining marks, a ZWJ emoji sequence, or a regional-indicator pair each come off whole. Hangul jamo and Indic conjuncts are approximated - erasing one of those may take two BACKSPACEs.

5. Frames

5.1 Client to room

{ "type": "rtt", "subprotocol": "t140", "seq": 1, "text": "<T140block>" }

• seq starts at 1 on every WebSocket open and increases by exactly one per frame from that sender. The room rejects a frame whose seq does not advance.
• text is a T140block: at most 1000 characters, non-empty after normalisation. A larger edit (a paste) is split across consecutive frames by the sender.
• Frames are paced at one per 300 ms. EN 301 549 clause 6.2.4 permits up to 500 ms of buffering (NOTE 2) and prefers 300 ms or less (NOTE 3).

5.2 Room to client

{
  "type": "rtt",
  "participantId": "…",
  "role": "host",
  "speakerName": "Sarah (Interviewer)",
  "channelId": 1756470000000,
  "seq": 1,
  "text": "<T140block>",
  "subprotocol": "t140",
  "direction": "received",
  "timestampMs": 1756470000000
}

• Relayed to every participant except the sender. A sender renders its own text locally; echoing it would put a network round trip between a keystroke and the sender seeing it.
• speakerName is the same label the room builds for live captions and the persisted transcript, so a person is named identically everywhere.
• channelId identifies the sender's channel and changes on every re-establishment. It is seeded from the wall clock so it increases even across a restart of the room server.

5.3 Channel state

{
  "type": "rtt_channel",
  "participantId": "…",
  "role": "guest",
  "speakerName": "Alex (Participant)",
  "channelId": 1756470000000,
  "state": "open"
}

Sent only for a participant who has already sent RTT in this room. open means their channel was re-established; closed means they left and their open line will never be completed.

5.4 Errors

Rejections come back to the sender as the room's ordinary error frame with one of these codes: rtt_forbidden (role may not send), rtt_invalid (malformed frame), rtt_rate_limited (retryable), rtt_sequence (the sequence number did not advance).

The frame carries seq, so the sender can say which of its lines failed. A rejection is a round trip and the participant will usually have typed on by the time it lands; a pane that could only blame its newest line would put "not delivered" on a sentence that arrived while saying nothing about the one that did not - a false claim in both directions at once. seq is absent in two cases: rtt_forbidden, where there is no frame behind it because the role may not send at all, and an rtt_invalid whose frame carried no usable sequence number of its own to quote back. In both the sender's most recent line is the one marked. A rejection whose seq matches nothing we still hold - the line aged out, or the channel was re-established while it was in flight - marks nothing, because a re-established channel already carries the missing text marker.

A rate-limited block is genuinely lost: the sender's seq has already advanced, so the next accepted block leaves a gap and every receiver marks it. That is the intended behaviour - the alternative is a receiver holding a sentence that silently lost its middle.

A rejection is shown to the sender, not only logged. The sending pane renders your own text the moment you compose it, because clause 6.2.4 gives the sender's own view a 500 ms budget that a network round trip would eat - which means every local line is a claim about delivery rather than a fact. On a surface whose whole purpose is that someone who cannot speak is being heard, an uncorrected false claim is the worst available failure. So an rtt_* error reaches the pane, and the line it belonged to says "not delivered" in text and is announced once to assistive technology, outside the quiet window that governs ordinary line announcements.

Nothing is retried automatically. The client holds the same character budget the room admits blocks with (section 7), so a well-behaved sender cannot outrun it; a rejection that survives that means the two ends disagree about the rules, and re-sending the same characters under a fresh sequence number would duplicate them in a receiver's buffer on the one occasion the original did arrive.

5.5 What survives a reconnect, and what must not

Section 5.4 of RFC 8865 forbids retransmission, and there are two opposite ways to get it wrong. They look identical from the sender's chair, because in both cases text is sitting on their screen that the other party does not have:

• Re-sending delivered text. Clearing the transmitted-text baseline is what causes this: the next diff runs from empty and re-sends the whole composition the participant is still looking at, so the receiver gets the same words twice in a marker-prefixed line.
• Dropping undelivered text. Freezing the whole composition causes this: whatever was typed since the last frame never left the tab, and freezing it excludes it from every frame after the break.

The line is therefore drawn at what the room actually received, not at what the field holds - and "received" has to mean the frame reached the socket, not that the sender decided to send one. The room's signalling transport drops a message when the socket is not open, which is correct for everything re-derivable (a ping reasserts itself, a user update is re-sent on reopen) and wrong for a per-character baseline. So the transport reports whether it wrote, the sender is handed that answer before any state moves, and a refused frame advances nothing: not the sequence number, not the baseline, not the queue, not the rate budget. The same characters are offered again on the next tick, and nothing renders them as sent in the meantime.

With that in place:

The one case this cannot resolve, and why that is the specification's answer

A synchronous WebSocket write is not a delivery receipt. A frame handed to a half-open connection is gone, and nothing at this layer can tell it apart from one that arrived: the failure is only observable later, when the socket closes. So on a re-establishment there is always a boundary of text whose fate is genuinely unknown.

There are only two ways to close that, and RFC 8865 rules out the one that would work. Re-sending the unconfirmed tail is a retransmission, which section 5.4 forbids in terms - "the sending endpoint MUST NOT retransmit T140blocks" - because a receiver that did get the original has no way to deduplicate it and would show the words twice, inside a sentence, with no indication which reading is right. An acknowledgement scheme would move the boundary rather than remove it (an ack can be lost as easily as a block) and would still leave retransmission as the only remedy, so it buys nothing it is allowed to spend.

The specification's answer to an ambiguity it cannot remove is to declare it, which is what the missing text marker is for and why clause 6.2.3 option (c) demands one. Reos therefore does the thing that is permitted, on both ends:

• every receiver marks the break, per section 5.4;
• and so does the sender's own pane. A sending client reopens its own channel through the same path a peer's break goes through, so a participant who reconnects mid-sentence is told their text may not have arrived rather than left looking at it and assuming. A reconnect nobody was typing through shows nothing, because nothing was in flight.

That is the whole of the residue: a bounded, disclosed uncertainty at each re-establishment, in place of either silent loss or duplicated words.

6. Loss indication

This is the clause 6.2.3(c) requirement, and it fires in three cases.

1. Sequence gap. A receiver that sees seq jump inserts U+FFFD at the point of the jump before applying the new block.
2. Channel re-establishment. A receiver that sees a new channelId for a sender it already holds text from closes that sender's open line and starts a new one beginning with U+FFFD.
3. Channel closed. A receiver told a sender's channel closed finishes that sender's open line rather than leaving it unterminated. No marker - nothing was lost, the sentence simply ended.

The marker cannot be erased. BACKSPACE stops at it, on both ends: the sender clamps erasures that would reach below what the current channel has sent, and a receiver refuses to erase a marker whatever arrives. Text before a marker is therefore unreachable, exactly as text before a completed line is. Without that rule a correction queued just before a reconnect - which begins with erasures aimed at the old line - would delete the disclosure and leave the loss, which is worse than the loss it was disclosing, and it is the one outcome clause 6.2.3 option (c) exists to prevent. The receiver-side half also holds against a peer whose client does not clamp.

The marker is not left as a bare glyph. The pane renders it as a labelled inline run reading "text may be missing", and the screen-reader announcement substitutes the same words, because U+FFFD read aloud is either silence or "replacement character".

7. Rate limits

Per sender, enforced by the room:

Both ends hold the same bucket. The room's admission control and the sending client are two users of one shared implementation of the character budget rather than two implementations of one rule. The sender sizes each block against its live budget, so a paste larger than the burst is spread across frames at the rate the room admits instead of going out whole and being refused - which is what used to happen, invisibly, to exactly the participant this feature exists for.

The client's copy is always the conservative one: both buckets start full when the channel opens, both refill on elapsed time, and the room sees a block strictly later than the client sent it, so the room has refilled at least as much as the client had when it decided. Neither side reads the other's clock.

The characters-per-frame ceiling is therefore a validation backstop rather than the binding constraint - the budget is always the smaller of the two.

8. Retention

RTT text is ephemeral. The room validates a block, relays it, and forgets it. Nothing is written to server-side storage, to the session transcript, to the recording, or to the database. A receiver keeps roughly the last 200 lines in the browser tab - only completed lines are dropped, so a line still being typed can hold the buffer a little above that - and closing the tab ends it.

9. AI-moderated interviews

RTT as specified here is not offered in AI-moderated interviews. That is a scoping decision with a known counter-argument, recorded so it is not mistaken for an analysis:

• Clause 6.2.1.1's precondition is "Where ICT is in a mode that provides a means for two-way voice communication". It contains no human-to-human qualifier, and an AI interview is plainly two-way voice.
• EN 301 549 V4.1.0 contemplates non-human parties explicitly (clause 6.2.2.2 NOTE: "who or what is currently communicating"; clause 6.2.9 NOTE 1: "a non-human process").
• Arguing the AI surface out of clause 6.2 lands it in clause 6.4 (alternatives to voice-based services, which names interactive voice response facilities), whose requirement - a complete path through the interview without hearing or speech - is larger, not smaller.

The AI interview surface is therefore not covered by this specification.

10. References

• ETSI EN 301 549 V3.2.1 (2021-03), clauses 6.2.1.1, 6.2.1.2, 6.2.2.1, 6.2.2.2, 6.2.2.3, 6.2.3, 6.2.4, and Annex C.
• ETSI EN 301 549 V4.1.0 (final draft, 2026-06), clause 6.2.10.
• IETF RFC 8865, T.140 Real-Time Text Conversation over WebRTC Data Channels.
• IETF RFC 4103, RTP Payload for Text Conversation.
• IETF RFC 9071, RTP-Mixer Formatting of Multiparty Real-Time Text (its section 3 tabulates the T.140 control codes).
• ITU-T Recommendation T.140 and its Addendum 1.
